Характеристики
- Продуктов сегмент
- Shaft adaptation
- Продукт
- Shaft couplings
- Диаметър на вала D1
- 10 mm
- Диаметър на вала D2
- 10 mm
- Съединител
- Bellows and claw coupling
- Тип на монтажната система
- Clamping hubs
- Дължина
- 31 mm
- Максимална скорост
- 10,000 min⁻¹
- Макс. въртящ момент
- 200 Ncm
- Описание
- Combination coupling: bellows & claw coupling, with emergency running property in the event of bellows fracture, shaft diameter 10 mm / 10 mm, maximum shaft offset: radial ± 0.3 mm, axial ± 0.45, angular ± 3°, max. speed 10,000 rpm, –30° to +120 °C, max. torque 200 Ncm; material: stainless steel bellows, stainless steel flange, for use with torque feather key
Сертификати
- China RoHS
- ✔
Класификации
- ECLASS 5.1.4
- 23031090
- ECLASS 6.0
- 23031090
- ECLASS 7.0
- 23031090
- ECLASS 8.0
- 23031090
- ECLASS 9.0
- 23031090
- ECLASS 10.0
- 23031090
- ECLASS 11.0
- 23031090
- ECLASS 12.0
- 23031090
- ECLASS 13.0
- 23031090
- ECLASS 14.0
- 23031090
- ECLASS 15.0
- 23031090
- ETIM 6.0
- EC002556
- ETIM 7.0
- EC002556
- ETIM 8.0
- EC002556
- ETIM 9.0
- EC002556
- ETIM 10.0
- EC002556
- UNSPSC 091201.0
- 31163000
- UNSPSC 100501.0
- 31163000
- UNSPSC 111201.0
- 31163014
- UNSPSC 120901.0
- 31163014
- UNSPSC 131201.0
- 31163014
- UNSPSC 140801.0
- 31163014
- UNSPSC 151101.0
- 31163014
- UNSPSC 160901.0
- 31163014
- UNSPSC 171001.0
- 31163014
- UNSPSC 180801.0
- 31163014
- UNSPSC 190501.0
- 31163014
- UNSPSC 200601.0
- 31163014
- UNSPSC 210901.0
- 31163014
- UNSPSC 220601.0
- 31163014
- UNSPSC 230701.0
- 31163014
- UNSPSC 240301.0
- 31163014
- UNSPSC 250901.0
- 31163014
- UNSPSC 260801.0
- 31163014
