41538 резултата за "SICK" · стр. 153/2077
YF2A14-020VB3XLEAX
Connectors and cables | Sensor-actuator cables | YF2A14-020VB3XLEAX | Description: Sensor/actuator cable, unshielded | Connection type head A: Female connector, M12, 4-pin, straight, A-coded | Connection type head B: Flying leads | Signal type: Sensor/actuator cable | Cable: 2 m, 4-wire, PVC | Application: Uncontaminated zones, Zones with chemicals
PBT-RB025SG1SSNAMA0Z
Pressure sensors | PBT | PBT-RB025SG1SSNAMA0Z | Pressure type: Gauge pressure | Pressure unit: bar | Measuring range: 0 bar ... 25 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: NBR | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire | Connection type
YMUSA4-020VG5MUSC4
Connectors and cables | Other connectors and cables | YMUSA4-020VG5MUSC4 | Connection type head A: Male connector, USB-C, 4-pin, straight | Connection type head B: Male connector, USB-A, 4-pin, straight | Cable: 2 m, PVC
VT12T-2N430
Photoelectric sensors | V12 | VT12T-2N430 | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Switching output: NPN | Switching mode: Light/dark switching | Connection type: Male connector M12, 4-pin | Light source: LED | Adjustment: Teach-in button, Wire/pin | Communication interface: -
PICS150-01000 LOC Pro
LiDAR sensors | picoScan100 | PICS150-01000 LOC Pro | Working range: 0.05 m ... 120 m | Scanning range: 75 m at 90% remission factor, 40 m at 10% remission factor | Angular resolution: 0.05°, 0.1°, 0.125°, 0.25°, 0.33°, 0.5° | Scanning frequency: 15 Hz, 20 Hz, 25 Hz | Integrated application: 2D Object Detection, LiDAR-LOC 2, Virtual Line Navigation, CODE-LOC, output of measurement data | Digital add-ons: Dynamic Sensing Profile package, Multi-echo technology, Data Reduction & Data Preparation pa
DBS36E-BBCP02048
Incremental encoders | DBS36/50 | DBS36E-BBCP02048 | Mechanical design: Blind hollow shaft 8 mm (Front clamp) | Communication interface: 7 V ... 30 V, TTL, RS-422 | Connection type: Cable, 8-wire, with male connector, M12, 8-pin, universal, 0.5 m | Pulses per revolution: 2,048
DLS40E-BEGV01000
Incremental encoders | DLS40 | DLS40E-BEGV01000 | Mechanical design: Blind hollow shaft 12 mm (Front clamp) | Communication interface: 10 V ... 27 V, HTL, Push pull | Connection type: Cable, 5-wire, radial, 2 m | Pulses per revolution: 1,000
DOL-2312-G20MLA3
Connectors and cables | Sensor-actuator cables | DOL-2312-G20MLA3 | Description: Incremental, shielded | Connection type head A: Female connector, M23, 12-pin, straight | Connection type head B: Flying leads | Signal type: Incremental | Cable: 20 m, 11-wire, PUR | Application: Zones with oils and lubricants
MZ2Q-CFLPSKU0
Cylinder sensors | MZ2Q-C | MZ2Q-CFLPSKU0 | Preferred manufacturer slot: Festo | Connection type: Cable, 4-wire, stripped, 2 m | Output function: 2 x N/O contact, IO-Link | Electrical wiring: DC 4-wire | Smart Sensor: Enhanced Sensing, efficient communication | Communication interface: IO-Link
CDF600-2201
Network devices | CDF | CDF600-2201 | Communication interface: PROFINET, Serial | Communication Interface detail: RS-232, RS-232 | Operating voltage: 10 V DC 30 V DC | Supported products: Lector series, CLV61x - CLV65x, CLV69x, RFID read/write device, Mobile handheld scanners
STE-0804-G
Connectors and cables | Field-wireable connectors | STE-0804-G | Description: Unshielded | Connection type head A: Male connector, M8, 4-pin, straight, A-coded | Connection systems: Screw-type terminals | Permitted cross-section: 0.14 mm² ... 0.5 mm²
PLB-52A0100
Robot guidance systems | PLB | PLB-52A0100 | Items supplied: C57 camera, PLB Application Software | Part size: (approx.) > 30 mm x 30 mm x 30 mm | Part characteristics: Simple and complex part shapes | Bin size: Large
TCT-2AAG10253MZ
Temperature sensors | TCT | TCT-2AAG10253MZ | Temperature measuring range: –50 °C ... +150 °C | Process connection: Thread G ¼ B | Insertion length/diameter of probe: 25 mm / 3 mm | Seal: Without seal | Output signal: 4 mA ... 20 mA, 2-wire | Connection type: M12 round connector x 1, 4-pin | Enclosure rating: IP67 | Communication interface: -
IME12-10NPOZC0S
Inductive proximity sensors | IME | IME12-10NPOZC0S | Housing: Standard design | Sensing range Sn: 10 mm | Installation type: Non-flush | Electrical wiring: DC 3-wire | Switching output: PNP | Output function: NC | Connection type: Male connector M12, 4-pin | Special features: Triple sensing range
PBT-RBX10SG1SSFAMA0Z
Pressure sensors | PBT | PBT-RBX10SG1SSFAMA0Z | Pressure type: Gauge pressure | Pressure unit: bar | Measuring range: 0 bar ... 0.1 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: FKM | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire | Connection typ
BEF-MA-WLMNTS-PAC5
Mounting systems | Brackets | BEF-MA-WLMNTS-PAC5 | Description: Wall-mounting kit; mounting element for wall-mounting of pressure switch PAC50 | Material: Plastic, steel | Details: Mounting element: polycarbonate, screws: steel, zinc-coated
GTE6-N1211S96
Photoelectric sensors | G6 | GTE6-N1211S96 | Sensing range max.: 10 mm ... 300 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Switching output: NPN | Switching mode: Light/dark switching | Connection type: Cable, 3-wire, 2 m | Light source: PinPoint LED | Type of light: Visible red light | Housing material: ABS/PC | Adjustment: Potentiometer | Special features: Mounting holes, M3 un-threaded | Housing: Rectangular
CMB18-12NPPEC0SA00
Capacitive proximity sensors | CMB | CMB18-12NPPEC0SA00 | Sensing range Sn: 0 mm ... 12 mm | Installation type: Non-flush | Electrical wiring: DC 4-wire | Connection type: Male connector M12, 4-pin | Switching output: PNP | Output function: Complementary | Smart Sensor: Enhanced Sensing, efficient communication, diagnosis, Smart Task base logics
YF2A2B-050S01M2D24
Connectors and cables | Other connectors and cables | YF2A2B-050S01M2D24 | Description: Sensor/actuator cable, shielded | Connection type head A: Female connector, M12, 12-pin, straight, A-coded | Connection type head B: Male connector, M12, 4-pin, straight, D-coded | Signal type: Sensor/actuator cable | Cable: 5 m, 4-wire, PUR, halogen-free | Application: Zones with oils and lubricants
GTB2F-F5131
Photoelectric sensors | G2 | GTB2F-F5131 | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switching output: PNP | Switching mode: Dark switching | Connection type: Cable with connector M8, 3-pin, 200 mm | Light source: PinPoint LED | Adjustment: None | Communication interface: -
