DFS60B-BBAK01024
Incremental encoders | DFS60 | DFS60B-BBAK01024 | Mechanical design: Blind hollow shaft 8 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 1,024
DAXSON-0200S4040901300
Linear encoders | DAX | DAXSON-0200S4040901300 | Design: DAX Slider | Communication interface: CANopen | Baud rate: 250 kbit/s | Node ID: 7Fh (127) | Connection type: Male connector, M12, 5-pin | Resolution: 10 µm | Measurement range: 0 mm ... 200 mm | Supply voltage: 24 V DC (± 20%) | Unusable range (zero zone/damping zone): 25 mm / 63 mm | Magnet type: Slide magnet MAG-S-H29-01
TPCC cooling housing Dx1000
Device protection and care | Cooling devices | TPCC cooling housing Dx1000 | Description: Cooler housing, Peltier cooling unit, polyamide 6 Due to space constraints, connecting cables with 90° angled, pre-assembled male connectors are required. | Usable for: Dx1000
DFS60B-BHEK01024
Incremental encoders | DFS60 | DFS60B-BHEK01024 | Mechanical design: Blind hollow shaft 15 mm (Front clamp) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 1,024
MLG05W-0A00N12501
Automation light grids | MLG-2 WebChecker | MLG05W-0A00N12501 | Device version: Web guiding | Option: None | Beam separation: 5 mm | Operating range: 2.5 m | Total measuring field width: 1,495 mm | Measuring field width detail (connection side/medium range/head side): 1,495 mm / 0 mm / 0 mm | Length of cable: 0.22 m, 0.27 m | Response time: 60.3 ms | Software feature (default setting - see technical data/features): 01
Connecting cable, 14-pin
Connectors and cables | Other connectors and cables | Connecting cable, 14-pin | Connection type head A: MOLEX 43025-14P | Connection type head B: Flying leads | Cable: 14-wire
DBS60E-BEAL00100
Incremental encoders | DBS60 | DBS60E-BEAL00100 | Mechanical design: Blind hollow shaft 12 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 100 | Flange type / stator coupling: 2-sided stator coupling, slot, screw hole circle 63–83 mm
WLA12L-1H162830A00
Photoelectric sensors | W12 | WLA12L-1H162830A00 | Sensing range min. / max.: 0 m / 11 m | Functional principle: Photoelectric retro-reflective sensor | Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics) | Switching output: Push-pull: PNP/NPN | Switching mode: Light/dark switching | Connection type: Cable, 4-wire, 2 m | Light source: Laser | Type of light: Visible red light | Laser class: 1 | Housing material: Zinc diecast | Adjustment: Teach-in butt
MAX48A-22JFDFA1500
Linear encoders | MAX | MAX48A-22JFDFA1500 | Type: Ø 48 mm 48f7 - IN Cylinder Mounting Ø48H8 | Pipe diameter / Damping zone / End cap: 36 mm / Flat | Supply voltage: 24 V DC (+8 V DC ... +32 V DC) | Communication interface: SAE J1939 | Connection type: Male connector, M12 type L (24x24 mm), 5-pin | Measuring range: 0 mm ... 1,500 mm
WTB9C-3P2462A71
Photoelectric sensors | W9 | WTB9C-3P2462A71 | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switching output: PNP | Switching mode: Light/dark switching | Connection type: Male connector M12, 4-pin | Light source: PinPoint LED | Adjustment: IO-Link, Teach-in button | Communication interface: IO-Link | Smart Sensor: Enhanced Sensing, efficient communication, Smart Task | Smart Task name: Counter + debouncing
PBT-RP200AG2SE0ALA0Z
Pressure sensors | PBT | PBT-RP200AG2SE0ALA0Z | Pressure type: Gauge pressure | Pressure unit: psi | Measuring range: 0 psi ... 200 psi | Accuracy: ≤ ± 0.5 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ female (EN 837) | Pressure port: Standard | Process temperature: –30 °C ... +100 °C | Seal: Without seal | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire |
AFM60E-S4AC001024
Absolute encoders | AFS/AFM60 SSI | AFM60E-S4AC001024 | Singleturn or multiturn version: Multiturn | Max. resolution: 10 bit x 12 bit (1,024 x 4,096) | Mechanical design: Solid shaft face mount flange 10 mm x 19 mm (With flat) | Communication interface: SSI, non programmable | Connection type: Male connector, M12, 8-pin, radial
DAXLAN-0450BA0C0000E00
Linear encoders | DAX | DAXLAN-0450BA0C0000E00 | Design: DAX Low Profile | Communication interface: - / Current | Current output: 4 mA ... 20 mA | Connection type: Male connector, M12, 5-pin | Measurement range: 0 mm ... 450 mm | Supply voltage: 24 V DC (± 20%) | Sequence of signals: Signal 1: rising, signal 2: falling | Unusable range (zero zone/damping zone): 55 mm / 63 mm | Magnet type: Small block magnet MAG-B-180-01
MAX48N-12E04DA0100
Linear encoders | MAX | MAX48N-12E04DA0100 | Type: Ø 48 mm 48f7 - IN Cylinder Mounting Ø48H8 | Pipe diameter / Damping zone / End cap: 30 mm / Flat | Supply voltage: 24 V DC (+8 V DC ... +32 V DC) | Communication interface: CANopen | Connection type: Male connector, M12 type S (20x20 mm), 5-pin | Measuring range: 0 mm ... 100 mm
DFS60B-S4EL00500
Incremental encoders | DFS60 | DFS60B-S4EL00500 | Mechanical design: Solid shaft face mount flange 10 mm x 19 mm (With flat) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 500
AFM60S-BFKN262144
Safety encoders | AFS/AFM60S Pro | AFM60S-BFKN262144 | Safety integrity level: SIL 3 (IEC 61508, IEC 61800-5-3) | Performance level: PL e (EN ISO 13849-1) | Singleturn or multiturn version: Multiturn | Max. resolution: 18 bit x 12 bit (262,144 x 4,096) | Mechanical design: Blind hollow shaft 1/2″ (with feather key groove) | Communication interface: SSI, SSI + Sin/Cos, non programmable | Connection type: Cable, 12-wire, radial, 10 m
SAS4-F028P3PS2T01
Automation light grids | SLG | SAS4-F028P3PS2T01 | Optical light exit: Flat | Aluminum stabilizer: With stabilizer | Beam separation: 40 mm | Cross beam/parallel beam: Cross beam active | Operating range: 3 m | Detection height: 280 mm | Response time: 57 ms
AFM60E-BEAK004096
Absolute encoders | AFS/AFM60 SSI | AFM60E-BEAK004096 | Singleturn or multiturn version: Multiturn | Max. resolution: 12 bit x 12 bit (4,096 x 4,096) | Mechanical design: Blind hollow shaft 12 mm (Front clamp) | Communication interface: SSI, non programmable | Connection type: Cable, 8-wire, universal, 1.5 m
DFS60B-BHAA04000
Incremental encoders | DFS60 | DFS60B-BHAA04000 | Mechanical design: Blind hollow shaft 15 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 4,000
GRTE18-N1162V
Photoelectric sensors | GR18 | GRTE18-N1162V | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Switching output: NPN | Switching mode: Light/dark switching | Connection type: Cable, 4-wire, 2 m | Light source: LED | Adjustment: Potentiometer | Communication interface: - | Included with delivery: Fastening nuts (2 x)
