41538 резултата за "SICK" · стр. 341/2077
FOC03-AM1N
Connectors and cables | Other connectors and cables | FOC03-AM1N | Connection type head A: Male connector | Connection type head B: Male connector
DFS60E-BEAL00360
Incremental encoders | DFS60 | DFS60E-BEAL00360 | Mechanical design: Blind hollow shaft 12 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 360
V2D8301P-1CCKDXAF1SXXXX
Machine vision | Inspector83x | V2D8301P-1CCKDXAF1SXXXX | License included: Intelligent Inspection License | Illumination: Integrated | Illumination color: White | Lens: 16 mm, C-mount | Working distance: 200 mm ... 2,500 mm | Sensor resolution: 1,232 px x 1,024 px (1.3 MP) | Sensor: CMOS Color | Optical focus: Adjustable focus
VLR-201RA4501
Reflectors and optics | Optical filters | VLR-201RA4501 | Description: Diffuser
WLA4SP-1H165130A00
Photoelectric sensors | W4 | WLA4SP-1H165130A00 | Sensing range min. / max.: 0 m / 7.1 m | Functional principle: Photoelectric retro-reflective sensor | Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics) | Switching output: Push-pull: PNP/NPN | Switching mode: Light switching | Connection type: Cable, 4-wire, 2 m | Light source: PinPoint LED | Type of light: Visible red light | Housing material: VISTAL® | Adjustment: Teach-in button, IO-Link | Smart
DFS60B-S4EK01250
Incremental encoders | DFS60 | DFS60B-S4EK01250 | Mechanical design: Solid shaft face mount flange 10 mm x 19 mm (With flat) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 1,250
DBS60E-BGEQD2048
Incremental encoders | DBS60 | DBS60E-BGEQD2048 | Mechanical design: Blind hollow shaft 14 mm (Front clamp) | Communication interface: 10 V ... 27 V, HTL, Push pull | Connection type: Cable, 8-wire, with male connector, M23, 12-pin, universal, 0.5 m | Pulses per revolution: 2,048 | Flange type / stator coupling: 1-sided stator coupling, slot, screw hole circle radius 31.5–48.5 mm
MLG05N-1345P10501
Automation light grids | MLG-2 | MLG05N-1345P10501 | Device version: ProNet – extended functionality including fieldbus | Option: None | Beam separation: 5 mm | Operating range: 5 m | Detection height: 1,345 mm | Length of cable: 0.22 m, 0.21 m | Response time: 22.1 ms | Software feature (default setting - see technical data/features): 01
PBT-RB600SM2SS0ALA0Z
Pressure sensors | PBT | PBT-RB600SM2SS0ALA0Z | Pressure type: Gauge pressure | Pressure unit: bar | Measuring range: 0 bar ... 600 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: M20 x 1.5 (DIN 16288) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: Without seal | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire | Co
PBT-RP3K0SN1SE0AMA0Z
Pressure sensors | PBT | PBT-RP3K0SN1SE0AMA0Z | Pressure type: Gauge pressure | Pressure unit: psi | Measuring range: 0 psi ... 3,000 psi | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: ¼'' NPT | Pressure port: Standard | Process temperature: –30 °C ... +100 °C | Seal: Without seal | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire | Connection
GRL18S-P1331
Photoelectric sensors | GR18 | GRL18S-P1331 | Functional principle: Photoelectric retro-reflective sensor | Functional principle detail: With minimum distance to reflector (dual lens system) | Switching output: PNP | Switching mode: Light switching | Connection type: Cable, 3-wire, 2 m | Light source: PinPoint LED | Adjustment: None | Communication interface: - | Included with delivery: Fastening nuts (2 x)
DOS-2107-W
Connectors and cables | Field-wireable connectors | DOS-2107-W | Description: Unshielded | Connection type head A: Female connector, Q7, 7-pin, angled, DC-coded | Connection systems: Screw-type terminals | Permitted cross-section: 0.25 mm² ... 1 mm²
ARS60-F4L02048
Absolute encoders | ARS60 | ARS60-F4L02048 | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 2,048 (11 bit) | Mechanical design: Solid shaft face mount flange 10 mm x 19 mm (With flat) | Communication interface: Parallel data world | Connection type: Cable, 22-wire, radial, 3 m
SYS/SGD-W4150010002BX3
Safety systems | Safeguard Detector | SYS/SGD-W4150010002BX3 | Product scope: System | Safeguard Detector variant: Box variant | Detection zone: 30 mm ... 150 mm | Items supplied: 1 × UE410-SD safety controller, 2 × WTB4F MultiPulse sensor 150 mm, software, operating instructions, connection diagram and SISTEMA file
RSB1-0607H051125NZ1BZZZP0B
Photoelectric sensors | Roller Sensor Bar | RSB1-0607H051125NZ1BZZZP0B | Sensing range min. / max.: 2 mm / 300 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Length of Sensor Bar: 607 mm | Number of beams: 8 | Beam separation: 51 mm | Switching output: NPN | Switching mode: Light switching | Connection type: Cable, 4-wire | Length of cable: 150 mm | Light source: LED | Type of light: Infrared light | Housing material: Aluminum (anodised)
DBS60E-R4AQD1024
Incremental encoders | DBS60 | DBS60E-R4AQD1024 | Mechanical design: Through hollow shaft 10 mm (rear clamping) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Cable, 8-wire, with male connector, M23, 12-pin, universal, 0.5 m | Pulses per revolution: 1,024 | Flange type / stator coupling: 1-sided stator coupling, slot, screw hole circle radius 31.5–48.5 mm
GTB6-P0211S54
Photoelectric sensors | G6 | GTB6-P0211S54 | Sensing range max.: 5 mm ... 250 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switching output: PNP | Switching mode: Light/dark switching | Connection type: Cable with connector M8, 4-pin, with knurled nut | Light source: PinPoint LED | Type of light: Visible red light | Housing material: ABS/PC | Adjustment: Potentiometer | Special features: PUR cable, with M8 male connector, 4-pin
DBS60E-TEEM03600
Incremental encoders | DBS60 | DBS60E-TEEM03600 | Mechanical design: Through hollow shaft 12 mm (Front clamp) | Communication interface: 10 V ... 27 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 5 m | Pulses per revolution: 3,600 | Flange type / stator coupling: 2-sided stator coupling, slot, screw hole circle 63–83 mm
MLG10N-1190P10501
Automation light grids | MLG-2 | MLG10N-1190P10501 | Device version: ProNet – extended functionality including fieldbus | Option: None | Beam separation: 10 mm | Operating range: 5 m | Detection height: 1,190 mm | Length of cable: 0.22 m, 0.21 m | Response time: 10.6 ms | Software feature (default setting - see technical data/features): 01
DBS60E-T5EQD1024
Incremental encoders | DBS60 | DBS60E-T5EQD1024 | Mechanical design: Through hollow shaft 12 mm (Front clamp) | Communication interface: 10 V ... 27 V, HTL, Push pull | Connection type: Cable, 8-wire, with male connector, M23, 12-pin, universal, 0.5 m | Pulses per revolution: 1,024 | Flange type / stator coupling: 1-sided stator coupling, slot, screw hole circle radius 31.5–48.5 mm
