Търсене в каталога
41538 резултата за "SICK" · стр. 291/2077
ARS60-H4L00360
Absolute encoders | ARS60 | ARS60-H4L00360 | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 360 | Mechanical design: Solid shaft face mount flange 10 mm x 19 mm (With flat) | Communication interface: Parallel data world | Connection type: Cable, 22-wire, radial, 3 m
DBS60E-TEEKC1000
Incremental encoders | DBS60 | DBS60E-TEEKC1000 | Mechanical design: Through hollow shaft 12 mm (Front clamp) | Communication interface: 10 V ... 27 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 1,000 | Flange type / stator coupling: Axial and radial register pin mounting, for 4 mm register pin
DFS60B-S1EA00028
Incremental encoders | DFS60 | DFS60B-S1EA00028 | Mechanical design: Solid shaft Servo flange 6 mm x 10 mm (With flat) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 28
PBT-AB6X0SG1SSFALA0Z
Pressure sensors | PBT | PBT-AB6X0SG1SSFALA0Z | Pressure type: Absolute pressure | Pressure unit: bar | Measuring range: 0 bar ... 6 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: FKM | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire | Connection ty
DBS50E-S5EL00500
Incremental encoders | DBS36/50 | DBS50E-S5EL00500 | Mechanical design: Solid shaft face mount flange 8 mm x 15.5 mm (With flat) | Communication interface: 7 V ... 30 V, HTL, Push-Pull | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 500
MAX48N-32C01CP1375
Linear encoders | MAX | MAX48N-32C01CP1375 | Type: Ø 48 mm 48f7 - IN Cylinder Mounting Ø48H8 | Pipe diameter / Damping zone / End cap: 63 mm / Flat | Supply voltage: 24 V DC (+8 V DC ... +32 V DC) | Communication interface: CANopen | Connection type: Male connector, M12 type S (20x20 mm), 5-pin | Measuring range: 0 mm ... 1,375 mm
DL100-22AA2211
Laser distance sensors | Dx100 | DL100-22AA2211 | Communication interface: EtherCAT® | Measuring range: 0.15 m ... 200 m, on “diamond grade” reflective tape | Laser class: 2 | Light source: Laser, red | Minimum response time: 2 ms | Digital output: 2 x push-pull: PNP/NPN | Multifunctional input (MF): 1 x MF1
AFM60I-BFAC262144
Absolute encoders | AFS/AFM60 SSI | AFM60I-BFAC262144 | Singleturn or multiturn version: Multiturn | Max. resolution: 18 bit x 12 bit (262,144 x 4,096) | Mechanical design: Blind hollow shaft 1/2″ (Front clamp) | Communication interface: SSI, non programmable | Connection type: Male connector, M12, 8-pin, radial | Encoder material / Enclosure rating: Stainless steel V2A / IP67
DOS-1804-G
Connectors and cables | Field-wireable connectors | DOS-1804-G | Description: Unshielded | Connection type head A: Female connector, M18, 4-pin, straight, A-coded | Connection systems: Screw-type terminals
AFS60B-TDPM032768
Absolute encoders | AFS/AFM60 SSI | AFS60B-TDPM032768 | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 32,768 (15 bit) | Mechanical design: Through hollow shaft 10 mm (Front clamp) | Communication interface: SSI, programmable | Connection type: Cable, 8-wire, universal, 5 m | Programming interface: Over handheld programming tool, over SOPAS
ZTB18-7AZ0C1S62
Photoelectric sensors | Z18 Simple Sense | ZTB18-7AZ0C1S62 | Communication interface: - | Mounting system type: Side (24.1 … 25.4 mm) | Sensor/ detection principle: Photoelectric proximity sensor, Background suppression | Sensing range: 100 mm | Light source, light type: PinPoint LED, Infrared light | Switching output Q1: Push-pull: PNP/NPN, Light switching | Switching output Q2: Not connected | Connection type: 300 mm
TMM22B-PKJ090
Inertial sensors | TMS/TMM22 | TMM22B-PKJ090 | Number of axis: 2 | Measuring range: ± 90° | Resolution: ≤ 0.01° | Communication interface: - / Current | Current output: 4 mA ... 20 mA | Programmable/configurable: yes | Programming interface: Over PGT-15 | 0-set function via hardware pin: yes | Housing material: Plastic (PA12), glass-fiber reinforced | Connection type: Cable, 5-wire, 0.5 m
LFV200-XXHRLTPM
Level sensors | LFV200 | LFV200-XXHRLTPM | Communication interface: - | Process connection: Conical coupling DN 25 acc. to DIN 11851 withUnion nut (PN 40, 316L, Ra < 0.8µm) | Probe length: 67 mm | Probe type: Tuning fork | Remote amplifier: No | Output signal: Transistor output PNP | Connection type: M12 round connector x 1, 4-pin | Process temperature: –40 °C ... +150 °C | Process pressure: –1 bar ... 64 bar | Wetted parts: Stainless steel 1.4404 / 316L | Housing material: Stainless steel 1.440
GROUND STRAP Set SIG350
Connectors and cables | Other connectors and cables | GROUND STRAP Set SIG350
DOL-0610G05M075KM1
Connectors and cables | Sensor-actuator cables | DOL-0610G05M075KM1 | Description: Unshielded | Connection type head A: Female connector, M26, 12-pin, straight | Connection type head B: Flying leads | Cable: 5 m, PVC | Connection systems: Flying leads | Note: Without EFI: Pin 9 and 10 not connected | Application: Uncontaminated zones, Zones with chemicals
DFS60E-BDEM00100
Incremental encoders | DFS60 | DFS60E-BDEM00100 | Mechanical design: Blind hollow shaft 10 mm (Front clamp) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 5 m | Pulses per revolution: 100
DBS60E-S1EK00010
Incremental encoders | DBS60 | DBS60E-S1EK00010 | Mechanical design: Solid shaft Servo flange 6 mm x 10 mm (With flat) | Communication interface: 10 V ... 27 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 10 | Flange type / stator coupling: Flange with 3 x M3 and 3 x M4
WTT190L-K1534
Laser distance sensors | WTT190 PowerProx | WTT190L-K1534 | Product version: PowerProx Small | Sensing range max.: 200 mm ... 3,000 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression, Optical time-of-flight | Switching output: PNP, NPN | Switching mode: Light/dark switching | Connection type: Cable, 5-wire, 2 m | Analog output: - | Communication interface: -
iE110-P05
Wire draw mechanism | Wire draw mechanism for rope pull switches | iE110-P05 | Product segment: Wire draw mechanism | Product: Wire draw mechanism for rope pull switches | Description: Rope accessory set, rope length 5 m | Items supplied: 2 cable clamps, 1 tension roller, 3 eyebolts, 5 m rope, 1 Allen wrench
DFS60B-BDAA01500
Incremental encoders | DFS60 | DFS60B-BDAA01500 | Mechanical design: Blind hollow shaft 10 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 1,500
