41538 резултата за "SICK" · стр. 225/2077
C4C-SV12030C10000, C4C-EV12030B10000
Safety light curtains | deTec | C4C-SV12030C10000, C4C-EV12030B10000 | Product version: deTec4 Core Vibes | System part: Pair | Application: Machines with strong shock or vibration loads | Safety level: PL e, SIL 3, Type 4 | Resolution: 30 mm | Scanning range: 3.8 m | Protective field height: 1,200 mm | Connection type: Plug, M12, 5-pin | Enclosure rating: IP65, IP67 | Items supplied: Sender, receiver, test rod with diameter corresponding to the resolution of the safety light curtain, safety ins
KHK53-AXR01700
Linear encoders | KH53 | KHK53-AXR01700 | System part: Read head | Communication interface: SSI | Measuring range: 0 m ... 1,700 m | Resolution: 0.1 mm | Repeatability: 0.3 mm | Supply voltage: 10 V ... 32 V | Connection type: Cable, 12-wire, 1.5 m
IME30-20BPOZC0K
Inductive proximity sensors | IME | IME30-20BPOZC0K | Housing: Short-body | Sensing range Sn: 20 mm | Installation type: Quasi-flush | Electrical wiring: DC 3-wire | Switching output: PNP | Output function: NC | Connection type: Male connector M12, 4-pin | Special features: Triple sensing range
WLF4FI-1G3111A0ZZZ
Photoelectric sensors | W4 | WLF4FI-1G3111A0ZZZ | Sensing range min. / max.: 0 m / 10 m | Functional principle: Photoelectric retro-reflective sensor | Functional principle detail: With minimum distance to reflector (dual lens system) | Switching output: Push-pull: PNP/NPN | Switching mode: Dark switching | Connection type: Cable, 3-wire, 2 m | Light source: PinPoint LED | Type of light: Infrared light | Housing material: VISTAL® | Adjustment: None | Housing: Rectangular
LL3-TG01
Fiber-optic sensors | Fiber-optic cables | LL3-TG01 | Functional principle: Through-beam system | Fiber-optic head design: Smooth sleeve, Long end sleeve | Fiber length: 2,000 mm | Smooth sleeve diameter: 3.7 mm | Fiber material: Plastic | Jacket material: Plastic | Fiber head material: Plastic | Included with delivery: FC fiber cutter (5304141)
PBS2-RB025SG1SSDNMA0Z
Pressure sensors | PBS plus | PBS2-RB025SG1SSDNMA0Z | Pressure type: Gauge pressure | Pressure unit: bar psi | Measuring range: 0 bar ... 25 bar, 0 psi ... 363 psi | Accuracy: ≤ ± 0.5 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: –20 °C ... +85 °C | Seal: NBR | Communication interface: IO-Link | Output signal: I
PBT-RB250SGTSSNALA0Z
Pressure sensors | PBT | PBT-RB250SGTSSNALA0Z | Pressure type: Gauge pressure | Pressure unit: bar | Measuring range: 0 bar ... 250 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ½ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: NBR | Communication interface: - | Output signal: 4 mA ... 20 mA, 2-wire | Connection typ
M2C-SA0430LA10, M2C-EA04300A10
Safety light-beam sensors | deTem | M2C-SA0430LA10, M2C-EA04300A10 | Product version: deTem2 Core | Functional principle: Sender/receiver | System part: Pair | Application: Normal industrial environment | Safety level: PL c, SIL 1, Type 2 | Functions: Protective operation | Scanning range: 17 m | Number of beams: 4 | Beam separation: 300 mm | Connection type: Plug, M12, 5-pin | Integrated laser alignment aid: no | Enclosure rating: IP65, IP67 | Items supplied: Sender, receiver, safety instructio
DUS60E-TDKC0ABA
Incremental encoders | DUS60 | DUS60E-TDKC0ABA | Mechanical design: Through hollow shaft 10 mm (Front clamp) | Communication interface: 4.75 V ... 30 V, TTL, HTL, programmable | Connection type: Male connector, M12, 8-pin, universal | Output function: A and B output | Flange type / stator coupling: 2-point stator coupling, slot, hole diameter 63 mm – 83 mm | Anti-dither: no
YG2A25-020UB6XLEAX
Connectors and cables | Sensor-actuator cables | YG2A25-020UB6XLEAX | Description: Sensor/actuator cable, shielded | Connection type head A: Female connector, M12, 5-pin, angled, A-coded | Connection type head B: Flying leads | Signal type: Sensor/actuator cable | Cable: 2 m, 5-wire, PUR, halogen-free | Application: Drag chain operation, Zones with oils and lubricants, Robot, Drag chain operation
ARS60-H1M32768
Absolute encoders | ARS60 | ARS60-H1M32768 | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 32,768 (15 bit) | Mechanical design: Solid shaft Servo flange 6 mm x 10 mm (With flat) | Communication interface: Parallel data world | Connection type: Cable, 22-wire, radial, 5 m
MPA-323THTU0
Cylinder sensors | MPA | MPA-323THTU0 | Measuring range: 323 mm | Connection type: Cable, 4-wire, stripped, 2 m | Switching output / output function / enclosure rating: Analog, IP65, IO-Link, IP67, IP68 | Electrical wiring: DC 4-wire | Smart Sensor: Enhanced Sensing, efficient communication, diagnosis | Communication interface: IO-Link
RSB1-0615F103050KH3EZZZZZZ
Photoelectric sensors | Roller Sensor Bar | RSB1-0615F103050KH3EZZZZZZ | Sensing range min. / max.: 2 mm / 300 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Length of Sensor Bar: 615 mm | Number of beams: 6 | Beam separation: 103 mm | Switching output: PNP: open collector | Switching mode: Light/dark switching | Connection type: Cable with connector M8, 4-pin, with knurled nut | Length of cable: 1 m | Light source: LED | Type of light: Infra
MB1-BS00
Actuators and bolts | MB1 | MB1-BS00 | Catch release button/ANSI-compliant locking mechanism: no | Escape release: no | Frame plate with latching function: no | Items supplied: Bolt unit, short frame plate, adapter for actuator mounting (MB1-BRNC), safety screws for installing provided adapters, Mounting instructions | Description: Complete set consisting of bolt unit with short frame plate and adapters for actuators
MAX48N-32V20K60767
Linear encoders | MAX | MAX48N-32V20K60767 | Type: Ø 48 mm 48f7 - IN Cylinder Mounting Ø48H8 | Pipe diameter / Damping zone / End cap: 63 mm / Flat | Supply voltage: 24 V DC (+8 V DC ... +32 V DC) | Communication interface: - / Voltage | Connection type: Connecting cable, 3-wire, 2,000 mm | Measuring range: 0 mm ... 767 mm | Output signal: 0.25 V DC ... 4.75 V DC
SFM60-HMBB3K02
Motor feedback systems | SFS/SFM60 | SFM60-HMBB3K02 | Communication interface: HIPERFACE® | Model: Absolute Multiturn | Type: Stand-alone | Sine/cosine periods per revolution: 1,024 | Safety system: no | Mechanical design: Blind hollow shaft | Connection type: Male connector, M12, 8-pin, radial | Technology: Optical | Operating temperature range: –40 °C ... +115 °C | Items supplied: M3 mounting screws for stator coupling not included with delivery.
VI83I-BU2023M0
Reflectors and optics | Illuminations | VI83I-BU2023M0 | Description: Integratable lighting, lighting color blue, narrow, suitable for lenses with a focal length of 35 mm, 50 mm and 75 mm
MLG30A-1920I10501
Automation light grids | MLG-2 | MLG30A-1920I10501 | Device version: Pro - Extended functionality | Inputs/outputs: RS-485 + 2 x Q (IO-Link) | Option: None | Beam separation: 30 mm | Operating range: 5 m | Detection height: 1,920 mm | Length of cable: 0.22 m, 0.27 m, 0.19 m | Response time: 6.3 ms | Software feature (default setting - see technical data/features): 01
HTB18-N4A2BH
Photoelectric sensors | H18 Sure Sense | HTB18-N4A2BH | Device version: Standard | Communication interface: - | Mounting system type: M18, head/side (24.1 … 25.4 mm) | Sensor/ detection principle: Photoelectric proximity sensor, Background suppression | Sensing range: 300 mm | Light source, light type: PinPoint LED, visible red light | Voltage type: DC | Switching output Q1: NPN, Light switching | Switching output Q2: NPN, Dark switching | Potentiometer, right: Sensing range | Potentiometer, lef
DUS60E-S8KF0BEB
Incremental encoders | DUS60 | DUS60E-S8KF0BEB | Mechanical design: Solid shaft face mount flange 1/4″ x 8 mm (With flat) | Communication interface: 4.75 V ... 30 V, TTL, HTL, programmable | Connection type: Male connector, M12, 4-pin, universal | Output function: CW and CCW output | Flange type / stator coupling: Face mount flange with 3 x M3 3 x M4 | Anti-dither: yes
