PBSH-CB010ST2S0NMA0Z
Pressure sensors | PBS Hygienic | PBSH-CB010ST2S0NMA0Z | Pressure type: Compound pressure | Pressure unit: bar | Measuring range: –1 bar ... 9 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: Tri-Clamp 2" (DIN 32676) | Process temperature: –20 °C ... +100 °C | Seal: Without seal | Communication interface: IO-Link | Output signal: IO-Link/PNP + 4 mA ... 20 mA |
IME30-10BNSZQDSS49
Inductive proximity sensors | IME | IME30-10BNSZQDSS49 | Housing: Standard design | Sensing range Sn: 10 mm | Installation type: Flush | Electrical wiring: DC 3-wire | Switching output: NPN | Output function: NO | Connection type: Cable with plug, M12, 4-pin, 0.26 m | Special features: Protective hose
MLG25N-1025E10501
Automation light grids | MLG-2 | MLG25N-1025E10501 | Device version: ProNet – extended functionality including fieldbus | Option: None | Beam separation: 25 mm | Operating range: 5 m | Detection height: 1,025 mm | Length of cable: 0.22 m, 0.21 m | Response time: 4.6 ms | Software feature (default setting - see technical data/features): 01
DBS60E-BDACD1024
Incremental encoders | DBS60 | DBS60E-BDACD1024 | Mechanical design: Blind hollow shaft 10 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Male connector, M12, 8-pin, radial | Pulses per revolution: 1,024 | Flange type / stator coupling: 1-sided stator coupling, slot, screw hole circle radius 31.5–48.5 mm
LFP0500-GANMB
Level sensors | LFP Inox | LFP0500-GANMB | Communication interface: IO-Link | Process connection: G ¾ A | Probe length: 500 mm | Probe type: Rod probe in hygienic design | Remote amplifier: No | Output signal: 1 x PNP + 1 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V | Connection type: Cable connection, 5-wire | Process temperature: –20 °C ... +150 °C | Process pressure: –1 bar ... 16 bar | Housing design: With viewing window made from PMMA (acrylic glass) | Wetted parts: Stainless steel 1.4404 / 31
DFS60B-S1EA00125
Incremental encoders | DFS60 | DFS60B-S1EA00125 | Mechanical design: Solid shaft Servo flange 6 mm x 10 mm (With flat) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 125
DFS60A-TFCA65536
Incremental encoders | DFS60 | DFS60A-TFCA65536 | Mechanical design: Through hollow shaft 1/2″ (Front clamp) | Communication interface: 10 V ... 32 V, TTL, RS-422 | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 65,536
STL-127SG15ME25KM0
Connectors and cables | Other connectors and cables | STL-127SG15ME25KM0 | Description: Sensor/actuator cable, shielded | Connection type head A: Male connector, M12, 8-pin, straight | Connection type head B: Flying leads | Signal type: Sensor/actuator cable | Cable: 15 m, 7-wire, PUR, halogen-free | Connection systems: Flying leads
DBS60E-B8ACD1024
Incremental encoders | DBS60 | DBS60E-B8ACD1024 | Mechanical design: Blind hollow shaft 15 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Male connector, M12, 8-pin, radial | Pulses per revolution: 1,024 | Flange type / stator coupling: 1-sided stator coupling, slot, screw hole circle radius 31.5–48.5 mm
DFS60B-S1AA01500
Incremental encoders | DFS60 | DFS60B-S1AA01500 | Mechanical design: Solid shaft Servo flange 6 mm x 10 mm (With flat) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 1,500
CLV612-C1000
Fixed mount barcode scanners | CLV61x | CLV612-C1000 | Optical focus: Fixed focus | Communication interface: Serial, CAN | Type: Cable connection variant | Max. reading distance: 93 mm | Code resolution: 0.1 mm ... 0.2 mm | Code printing process: Label (printed codes) | Sensor type: Raster scanner | Window material: Glass | Cold storage applications: no | Enclosure rating: IP65
AFM60E-TBAM004096
Absolute encoders | AFS/AFM60 SSI | AFM60E-TBAM004096 | Singleturn or multiturn version: Multiturn | Max. resolution: 12 bit x 12 bit (4,096 x 4,096) | Mechanical design: Through hollow shaft 8 mm (Front clamp) | Communication interface: SSI, non programmable | Connection type: Cable, 8-wire, universal, 5 m
AFM60B-TBRA032768
Absolute encoders | AFS/AFM60 SSI | AFM60B-TBRA032768 | Singleturn or multiturn version: Multiturn | Max. resolution: 15 bit x 12 bit (32,768 x 4,096) | Mechanical design: Through hollow shaft 8 mm (Front clamp) | Communication interface: SSI, SSI + incremental, programmable | Connection type: Male connector, M23, 12-pin, radial | Programming interface: Over handheld programming tool, over SOPAS
DFS60B-THEM00500
Incremental encoders | DFS60 | DFS60B-THEM00500 | Mechanical design: Through hollow shaft 15 mm (Front clamp) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Cable, 8-wire, universal, 5 m | Pulses per revolution: 500
DBS60E-BDFK00360
Incremental encoders | DBS60 | DBS60E-BDFK00360 | Mechanical design: Blind hollow shaft 10 mm (Front clamp) | Communication interface: 4.5 V ... 30 V, TTL, HTL, HTL | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 360 | Flange type / stator coupling: 2-sided stator coupling, slot, screw hole circle 63–83 mm
WSE280-2R4331
Photoelectric sensors | W280 | WSE280-2R4331 | Functional principle: Through-beam photoelectric sensor | Switching output: Relay | Switching mode: Light switching | Connection type: Cable gland | Light source: LED | Adjustment: Potentiometer | Communication interface: - | Included with delivery: Mounting bracket BEF-W280
WLG4FP-1G312130ZZZ
Photoelectric sensors | W4 | WLG4FP-1G312130ZZZ | Sensing range min. / max.: 15 mm / 4.5 m | Functional principle: Photoelectric retro-reflective sensor | Functional principle detail: ClearSens, With minimum distance to reflector (dual lens system) | Switching output: Push-pull: PNP/NPN | Switching mode: Light switching | Connection type: Cable, 3-wire, 2 m | Light source: PinPoint LED | Type of light: Visible red light | Housing material: VISTAL® | Adjustment: Teach-in button | Housing: Rectang
MPS-100CLTQ0
Cylinder sensors | MPS-C | MPS-100CLTQ0 | Measuring range: 100 mm | Connection type: Cable with plug, M12, 4-pin, 0.3 m | Switching output / output function / enclosure rating: Analog, IP67, IO-Link | Electrical wiring: DC 4-wire | Smart Sensor: Enhanced Sensing, efficient communication, diagnosis | Communication interface: IO-Link
THTS-1AAT20506MZ
Temperature sensors | THTS | THTS-1AAT20506MZ | Temperature measuring range: –50 °C ... +150 °C | Process connection: Tri-Clamp 2" | Insertion length/diameter of probe: 50 mm / 6 mm | Seal: Without seal | Output signal: 4 mA ... 20 mA, 2-wire | Connection type: M12 round connector x 1, 4-pin | Enclosure rating: IP67, IP69 | Communication interface: -
MLG05W-0424N12501
Automation light grids | MLG-2 WebChecker | MLG05W-0424N12501 | Device version: Web guiding | Option: None | Beam separation: 5 mm | Operating range: 2.5 m | Total measuring field width: 1,495 mm | Measuring field width detail (connection side/medium range/head side): 595 mm / 305 mm / 595 mm | Length of cable: 0.22 m, 0.27 m | Response time: 48.5 ms | Software feature (default setting - see technical data/features): 01
