DFS60E-S1EA00150
Incremental encoders | DFS60 | DFS60E-S1EA00150 | Mechanical design: Solid shaft Servo flange 6 mm x 10 mm (With flat) | Communication interface: 10 V ... 32 V, HTL, Push pull | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 150
VMS5200-x-2
Track and trace systems | VMS4x00/5x00 | VMS5200-x-2 | Conveyor type: Cross-belt sorter | Legal-for-trade: yes | Touching objects: no | Side-by-side: no | Deformation detection: no | Transport speed: 0.5 m/s 4 m/s | Accuracy of object coverage: ≥ 5 mm ≥ 5 mm ± 2 mm, ≥ 0.2 ″ ≥ 0.2 ″ ± 0.1 ″ | Maximum object size: 2,500 mm x 1,600 mm x 1,100 mm, 98 ″ x 63 ″ x 43 ″
GTE20G-1H111170ZZZ
Photoelectric sensors | G20 | GTE20G-1H111170ZZZ | Sensing range min. / max.: 0.02 m / 2 m | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Switching output: Push-pull: PNP/NPN | Switching mode: Light/dark switching | Connection type: Cable, 4-wire, 2 m | Light source: LED | Type of light: Visible red light | Housing material: ABS | Adjustment: Potentiometer | Housing: Rectangular
DAXTAN-0180RA1F0100E00
Linear encoders | DAX | DAXTAN-0180RA1F0100E00 | Design: DAX Threaded | Communication interface: - / Current | Current output: 4 mA ... 20 mA | Connection type: Male connector, M12, 5-pin | Measurement range: 0 mm ... 180 mm | Supply voltage: 24 V DC (± 20%) | Sequence of signals: Signal 1: rising, signal 2: falling | Unusable range (zero zone/damping zone): 50 mm / 63 mm | Magnet type: Ring magnet MAG-O-330-01 | Thread offset: Without thread offset | Thread shape: M18 x 1.5
DFS60E-TECL01000
Incremental encoders | DFS60 | DFS60E-TECL01000 | Mechanical design: Through hollow shaft 12 mm (Front clamp) | Communication interface: 10 V ... 32 V, TTL, RS-422 | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 1,000
PL25FA
Reflectors and optics | Reflectors | PL25FA | Description: Fine triple, planar, suitable for laser sensors | Dimensions: 75 mm 6.8 mm | Ambient operating temperature: –30 °C ... +65 °C
MLG50N-2200N10501
Automation light grids | MLG-2 | MLG50N-2200N10501 | Device version: ProNet – extended functionality including fieldbus | Option: None | Beam separation: 50 mm | Operating range: 5 m | Detection height: 2,200 mm | Length of cable: 0.22 m, 0.21 m | Response time: 4.8 ms | Software feature (default setting - see technical data/features): 01
AFS60B-TGAA032768
Absolute encoders | AFS/AFM60 SSI | AFS60B-TGAA032768 | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 32,768 (15 bit) | Mechanical design: Through hollow shaft 14 mm (Front clamp) | Communication interface: SSI, non programmable | Connection type: Male connector, M23, 12-pin, radial
MLG05W-0236H52501
Automation light grids | MLG-2 WebChecker | MLG05W-0236H52501 | Device version: Web guiding | Option: Protective housing IP69K | Beam separation: 5 mm | Operating range: 2.5 m | Total measuring field width: 1,645 mm | Measuring field width detail (connection side/medium range/head side): 295 mm / 455 mm / 895 mm | Length of cable: 1.4 m, 1.4 m | Response time: 48.5 ms | Software feature (default setting - see technical data/features): 01
C4P-SA16511A00, C4P-EA16511C00
Safety light curtains | deTec | C4P-SA16511A00, C4P-EA16511C00 | Product version: deTec4 | System part: Pair | Application: Normal industrial environment | Safety level: PL e, SIL 3, Type 4 | Resolution: 14 mm | Scanning range: 20 m | Protective field height: 1,650 mm | Connection type: Depending on system plug (M12 male connector, 5-pin or 8-pin) | Extension connection: Depending on system plug (without extension connection or with M12 female connector, 5-pin) | Enclosure rating: IP65, IP67 | I
PBT-RM4X0AG1SSNVMC0Z
Pressure sensors | PBT | PBT-RM4X0AG1SSNVMC0Z | Pressure type: Gauge pressure | Pressure unit: MPa | Measuring range: 0 MPa ... 4 MPa | Accuracy: ≤ ± 0.5 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: NBR | Communication interface: - | Output signal: 0 V ... 10 V, 3-wire | Connection type:
MAX48N-22A10AA0725
Linear encoders | MAX | MAX48N-22A10AA0725 | Type: Ø 48 mm 48f7 - IN Cylinder Mounting Ø48H8 | Pipe diameter / Damping zone / End cap: 36 mm / Flat | Supply voltage: 24 V DC (+8 V DC ... +32 V DC) | Communication interface: - / Current | Connection type: Male connector, M12 type S (20x20 mm), 4-pin | Measuring range: 0 mm ... 725 mm
DFS21A-KFA1C065536
Incremental encoders | DFS2x | DFS21A-KFA1C065536 | Mechanical design: Through hollow shaft 1/2″ (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422, non programmable | Connection type: Male connector, M12, 8-pin, radial | Pulses per revolution: 65,536 | Flange type / stator coupling: 2-point stator coupling
AFS60A-BCIB262144
Absolute encoders | AFS/AFM60 Ethernet | AFS60A-BCIB262144 | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 262,144 (18 bit) | Mechanical design: Blind hollow shaft 3/8″ (Front clamp) | Communication interface: EtherNet/IP™, programmable | Connection type: Male connector, 1x, M12, 4-pin, axial, Female connector, 2x, M12, 4-pin, axial | Programming interface: Over webserver, over PLC-Engineering-Tool
C4MT-06614ABB04FE0
Safety light curtains | miniTwin | C4MT-06614ABB04FE0 | Usage: miniTwin4 as host for 2- or 3-device cascade, miniTwin4 as middle guest for 3-device cascade | Mounting system type: C-fix or L-fix bracket | Safety level: PL e, SIL 3, Type 4 | Resolution: 14 mm | Scanning range: 5 m | Protective field height: 660 mm | Connection type: Plug, M12, 5-pin | Extension connection: Female connector M12, 5-pin | Enclosure rating: IP65 | Items supplied: Twin stick, system plug, C-Fix and L-Fix bracket, 2 pi
EKS36-2KF0A0S13
Motor feedback systems | EKS/EKM36 | EKS36-2KF0A0S13 | Communication interface: HIPERFACE DSL® | Model: Absolute Singleturn | Type: For integration | Resolution per revolution: 18 bit | Safety system: yes | Mechanical design: Tapered shaft | Connection type: Male connector, 4-pin | Technology: Optical | Operating temperature range: –20 °C ... +115 °C | Items supplied: M3 mounting screws for stator coupling not included with delivery. | Specialty: High impedance capacitive connection between enco
DT50-N2123
Laser distance sensors | Dx50 | DT50-N2123 | Measuring range: 200 mm ... 13,000 mm, 90% remission factor, 200 mm ... 5,800 mm, 18% remission factor, 200 mm ... 3,400 mm, 6% remission factor | Laser class: 1 | Light source: Laser, red | Minimum response time: 15 ms | Digital output: 1 x NPN | Type of analog output: Current output | Multifunctional input (MF): 1 x
DBS36E-S3EN01000
Incremental encoders | DBS36/50 | DBS36E-S3EN01000 | Mechanical design: Solid shaft face mount flange 6 mm x 12 mm (With flat) | Communication interface: 7 V ... 30 V, HTL, Push-Pull | Connection type: Cable, 8-wire, universal, 10 m | Pulses per revolution: 1,000
DFS60A-BAPA65536
Incremental encoders | DFS60 | DFS60A-BAPA65536 | Mechanical design: Blind hollow shaft 6 mm (Front clamp) | Communication interface: 4.5 V ... 32 V, TTL, HTL, programmable | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 65,536
WL12G-3K2572
Photoelectric sensors | W12G | WL12G-3K2572 | Sensing range max.: 0 m ... 4 m | Functional principle: Photoelectric retro-reflective sensor | Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics) | Switching output: PNP | Switching mode: Light/dark switching | Connection type: Plug, M12, 5-pin | Light source: PinPoint LED | Type of light: Visible red light | Housing material: Zinc diecast | Adjustment: Teach-in button | Housing: Rectangular | Included w
