DFS60B-S4AA03142
Incremental encoders | DFS60 | DFS60B-S4AA03142 | Mechanical design: Solid shaft face mount flange 10 mm x 19 mm (With flat) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Male connector, M23, 12-pin, radial | Pulses per revolution: 3,142
MLG05W-0400H12503
Automation light grids | MLG-2 WebChecker | MLG05W-0400H12503 | Device version: Web guiding | Option: None | Beam separation: 5 mm | Operating range: 2.5 m | Total measuring field width: 595 mm | Measuring field width detail (connection side/medium range/head side): 595 mm / 0 mm / 0 mm | Length of cable: 0.22 m, 0.27 m | Response time: 24.9 ms | Software feature (default setting - see technical data/features): 03
LBV310-XXANDT8MX
Level sensors | LBV3xx | LBV310-XXANDT8MX | Communication interface: - | Process connection: 1 1/2" NPT PN 25 | Probe length: 220 mm | Probe type: Tuning fork | Remote amplifier: No | Output signal: 1 x PNP/NPN | Connection type: M20 x 1.5 | Process temperature: –50 °C ... +150 °C | Process pressure: –1 bar ... 25 bar | Wetted parts: Stainless steel 1.4404 / 316L | Housing material: Stainless steel 1.4404 / 316L | Enclosure rating: IP66, IP67 | Display: no | PWIS-cleaned: no | Bluetooth: no
DAXSAN-0500SA040900D00
Linear encoders | DAX | DAXSAN-0500SA040900D00 | Design: DAX Slider | Communication interface: - / Current | Current output: 4 mA ... 20 mA | Connection type: Male connector, M12, 5-pin | Measurement range: 0 mm ... 500 mm | Supply voltage: 24 V DC (± 20%) | Sequence of signals: Rising | Unusable range (zero zone/damping zone): 25 mm / 63 mm | Magnet type: Slide magnet MAG-S-H29-01
GE2S-E1311
Photoelectric sensors | G2 | GE2S-E1311 | Functional principle: Through-beam photoelectric sensor | Switching output: NPN | Switching mode: Dark switching | Connection type: Cable, 3-wire, 2 m | Adjustment: None | Communication interface: -
AFS60S-TCSM262144
Safety encoders | AFS/AFM60S Pro | AFS60S-TCSM262144 | Safety integrity level: SIL 3 (IEC 61508, IEC 61800-5-3) | Performance level: PL e (EN ISO 13849-1) | Singleturn or multiturn version: Singleturn | Number of steps per revolution: 262,144 (18 bit) | Mechanical design: Through hollow shaft 3/8″ (with feather key groove) | Communication interface: SSI, SSI + Sin/Cos, programmable | Connection type: Cable, 12-wire, radial, 5 m
PBT-RB010SG1SSFVMC0Z
Pressure sensors | PBT | PBT-RB010SG1SSFVMC0Z | Pressure type: Gauge pressure | Pressure unit: bar | Measuring range: 0 bar ... 10 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: FKM | Communication interface: - | Output signal: 0 V ... 10 V, 3-wire | Connection type:
MLG10A-0740B10801
Automation light grids | MLG-2 | MLG10A-0740B10801 | Device version: Pro - Extended functionality | Inputs/outputs: 2 x analog + 2 x Q (IO-Link) | Option: None | Beam separation: 10 mm | Operating range: 8.5 m | Detection height: 740 mm | Length of cable: 0.22 m, 0.27 m, 0.19 m | Response time: 7.1 ms | Software feature (default setting - see technical data/features): 01
HL18L-A4A5BA
Photoelectric sensors | H18 Sure Sense | HL18L-A4A5BA | Device version: Standard | Communication interface: - | Mounting system type: M18, head/side (24.1 … 25.4 mm) | Sensor/ detection principle: Photoelectric retro-reflective sensor, With minimum distance to reflector (dual lens system) | Sensing range: 12 m | Light source, light type: Laser, visible red light | Voltage type: DC | Switching output Q1: PNP, Dark switching | Switching output Q2: NPN, Dark switching | Potentiometer, right: None |
PBT-RB010SG1SSNWMA0Z
Pressure sensors | PBT | PBT-RB010SG1SSNWMA0Z | Pressure type: Gauge pressure | Pressure unit: bar | Measuring range: 0 bar ... 10 bar | Accuracy: ≤ ± 1 %, of the span (including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement as per IEC 61298-2)) | Process connection: G ¼ A (ISO 1179-2) | Pressure port: Standard | Process temperature: 0 °C ... +80 °C | Seal: NBR | Communication interface: - | Output signal: 1 V ... 5 V, 3-conductor | Connection ty
VTF180-2F32419
Photoelectric sensors | V180 | VTF180-2F32419 | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Switching output: PNP | Switching mode: Light switching | Connection type: Male connector M12, 4-pin | Light source: LED | Adjustment: Potentiometer | Communication interface: -
DBS50E-S5AL01024
Incremental encoders | DBS36/50 | DBS50E-S5AL01024 | Mechanical design: Solid shaft face mount flange 8 mm x 15.5 mm (With flat) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 1,024
DBS60E-TJFJK0060
Incremental encoders | DBS60 | DBS60E-TJFJK0060 | Mechanical design: Through hollow shaft 5/8″ (Front clamp) | Communication interface: 4.5 V ... 30 V, TTL, HTL, HTL | Connection type: Cable, 8-wire, universal, 0.5 m | Pulses per revolution: 60 | Flange type / stator coupling: Without stator coupling, flange with 3 x M3, 3 x M4, axial register pin mounting, for 4 mm register pin
DOL-1406-W02M
Connectors and cables | Other connectors and cables | DOL-1406-W02M | Description: Sensor/actuator cable, unshielded | Connection type head A: Female connector, 6-pin, angled, AC/UC-coded | Connection type head B: Flying leads | Signal type: Sensor/actuator cable | Cable: 2 m, PVC
HL18-N1G3BD
Photoelectric sensors | H18 Sure Sense | HL18-N1G3BD | Device version: Standard | Communication interface: - | Mounting system type: M18, head/side (24.1 … 25.4 mm) | Sensor/ detection principle: Photoelectric retro-reflective sensor, With minimum distance to reflector (dual lens system) | Sensing range: 6.5 m | Light source, light type: PinPoint LED, visible red light | Voltage type: DC | Switching output Q1: NPN, Light switching | Switching output Q2: NPN, Dark switching | Potentiometer, right
DFS60A-THCL65536
Incremental encoders | DFS60 | DFS60A-THCL65536 | Mechanical design: Through hollow shaft 15 mm (Front clamp) | Communication interface: 10 V ... 32 V, TTL, RS-422 | Connection type: Cable, 8-wire, universal, 3 m | Pulses per revolution: 65,536
DAXSAN-0300CA0G0900W01
Linear encoders | DAX | DAXSAN-0300CA0G0900W01 | Design: DAX Slider | Communication interface: - / Current | Current output: 4 mA ... 20 mA | Connection type: Male connector, M12, 8-pin | Measurement range: 0 mm ... 300 mm | Supply voltage: 24 V DC (± 20%) | Sequence of signals: Signal 1: rising, signal 2: falling | Unusable range (zero zone/damping zone): 25 mm / 63 mm | Magnet type: C-magnet MAG-C-330-01
DBS60E-RJFK02000
Incremental encoders | DBS60 | DBS60E-RJFK02000 | Mechanical design: Through hollow shaft 5/8″ (rear clamping) | Communication interface: 4.5 V ... 30 V, TTL, HTL, HTL | Connection type: Cable, 8-wire, universal, 1.5 m | Pulses per revolution: 2,000 | Flange type / stator coupling: 2-sided stator coupling, slot, screw hole circle 63–83 mm
DBS60E-B8APC1024
Incremental encoders | DBS60 | DBS60E-B8APC1024 | Mechanical design: Blind hollow shaft 15 mm (Front clamp) | Communication interface: 4.5 V ... 5.5 V, TTL, RS-422 | Connection type: Cable, 8-wire, with male connector, M12, 8-pin, universal, 0.5 m | Pulses per revolution: 1,024 | Flange type / stator coupling: Axial and radial register pin mounting, for 4 mm register pin
RSB1-0750D160140FZ0BS06ZZZ
Photoelectric sensors | Roller Sensor Bar | RSB1-0750D160140FZ0BS06ZZZ | Sensing range min. / max.: 2 mm / 300 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Energetic | Length of Sensor Bar: 750 mm | Number of beams: 4 | Beam separation: 160 mm | Switching output: PNP | Connection type: Cable with special plug, M8, 4-pin, 137 mm | Length of cable: 100 mm | Light source: LED | Type of light: Infrared light | Housing material: Aluminum (anodised) | Specia
