Серия OD2000
6 варианта от SICK. Изберете модела, който отговаря на приложението ви, или попитайте нас.
OD2000-0301T15
Laser distance sensors | OD2000 | OD2000-0301T15 | Communication interface: IO-Link | Digital output: 2 x PNP/NPN, selectable | Type of analog output: Current output / voltage output | Measuring range: 25 mm ... 35 mm | Repeatability: 0.1 µm | Laser class: 1 | Typ. light spot size (distance): Ø 50 µm (30 mm) | Housing material: Plastic | Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm
OD2000-0501T15
Laser distance sensors | OD2000 | OD2000-0501T15 | Communication interface: IO-Link | Digital output: 2 x PNP/NPN, selectable | Type of analog output: Current output / voltage output | Measuring range: 40 mm ... 60 mm | Repeatability: 0.2 µm | Laser class: 1 | Typ. light spot size (distance): Ø 70 µm (50 mm) | Housing material: Plastic | Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm
OD2000-1301T15
Laser distance sensors | OD2000 | OD2000-1301T15 | Communication interface: IO-Link | Digital output: 2 x PNP/NPN, selectable | Type of analog output: Current output / voltage output | Measuring range: 60 mm ... 200 mm | Repeatability: 4 µm | Laser class: 1 | Typ. light spot size (distance): Ø 300 µm (130 mm) | Housing material: Plastic | Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm
OD2000-2452T15
Laser distance sensors | OD2000 | OD2000-2452T15 | Communication interface: IO-Link | Digital output: 2 x PNP/NPN, selectable | Type of analog output: Current output / voltage output | Measuring range: 70 mm ... 420 mm | Repeatability: 10 µm | Laser class: 2 | Typ. light spot size (distance): Ø 500 µm (245 mm) | Housing material: Plastic | Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm
OD2000-3502T15
Laser distance sensors | OD2000 | OD2000-3502T15 | Communication interface: IO-Link | Digital output: 2 x PNP/NPN, selectable | Type of analog output: Current output / voltage output | Measuring range: 100 mm ... 600 mm | Repeatability: 20 µm | Laser class: 2 | Typ. light spot size (distance): Ø 600 µm (350 mm) | Housing material: Plastic | Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm
OD2000-7002T15
Laser distance sensors | OD2000 | OD2000-7002T15 | Communication interface: IO-Link | Digital output: 2 x PNP/NPN, selectable | Type of analog output: Current output / voltage output | Measuring range: 200 mm ... 1,200 mm | Repeatability: 100 µm | Laser class: 2 | Typ. light spot size (distance): Ø 1 mm (700 mm) | Housing material: Plastic | Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm
